Precision Stainless Steel Rollenband Excenter Screw 304/316 Corrosion-Resistant Custom Sizes & Surface Finishes
Produktdetails:
| Herkunftsort: | China |
| Markenname: | guanbiao |
| Zertifizierung: | ISO, GB, BS, DIN, ANSI,JIS |
| Modellnummer: | 4.9*10.5 |
Zahlung und Versand AGB:
| Min Bestellmenge: | 50000 Stück |
|---|---|
| Preis: | USD0.054/piece |
| Verpackung Informationen: | Karton +pallets des Kästchens +outer der Plastiktasche 1 |
| Lieferzeit: | 10-15 Arbeitstage |
| Zahlungsbedingungen: | T/T |
| Versorgungsmaterial-Fähigkeit: | 100000 Stück/Tag |
|
Detailinformationen |
|||
| Material: | Edelstahl: 201 | Herstellungsprozess: | Kalte Überschrift, kaltes Schmieden |
|---|---|---|---|
| Oberflächenende/Behandlung: | Polieren, Passivierung | Größe: | 4.9*10.5 |
| Paket: | 1000 Stück | Einzigartig: | 7.5g |
| Farbe: | Natürliche Farbe des Edelstahls | Hauptgröße: | 9.5 mm |
| Kopf lang: | 6.0 mm | ||
Produkt-Beschreibung
Our Stainless Steel Rollenband Excenter Screws are engineered for high-precision eccentric adjustment in harsh environments. Made from AISI 304/316 stainless steel, these screws offer superior corrosion resistance, durability, and load-bearing capacity, ideal for:
✔️ Industrial machinery alignment
✔️ Automotive assembly systems
✔️ Medical equipment adjustments
✔️ Marine and chemical applications
Key Features
✅ Material: AISI 304/316 stainless steel (optional 316L for acidic environments)
✅ Eccentricity Range: 0.5mm – 5.0mm (customizable)
✅ Surface Finishes: Mirror polish, electropolish, sandblasted, or passivated
✅ Thread Types: Metric, UNC/UNF, or custom threads
✅ Certifications: ISO 9001, RoHS compliant
Technical Parameters (Standard Specifications)
| Parameter | Details | Options |
|---|---|---|
| Material | AISI 430F/304/316 Stainless Steel | 316L, 17-4PH (on request) |
| Diameter (D) | M4 – M20 | Custom diameters available |
| Eccentricity (e) | 0.5mm – 5.0mm | ±0.02mm tolerance |
| Thread Length | 10mm – 100mm | Adjustable per order |
| Head Style | Hex socket, slotted, or knurled | Other designs acceptable |
| Surface Treatment | Electropolished (standard) | Mirror polish, sandblasted, PTFE coated |
| Hardness | 150-200 HV (304) / 180-220 HV (316) | Hardened versions up to 45 HRC |
| Temperature Range | -50°C to +300°C (316 resistant to 800°C) |
Why Choose Our Rollenband Excenter Screws?
